Various fields where the production of a free powder sample is required.
We have successfully processed samples in the following areas: Beverage, Flavours and colourings, Milk and egg products, Plant and vegetable extracts, Pharmaceuticals, Synthetics Heat sensitive materials, Plastics polymers and resins, Perfumes, Blood, Ceramics and superconductors Biochemicals, Dyestuffs, Soaps and detergents, Foodstuffs, Adehesives, Oxides, Textiles, Bones, Teeth and tooth amalgam and many others.
Parameter
Name |
OLT-SD10L |
Inlet air temperature control |
≤30-300 °C. |
Outlet air temperature control |
<30 ~ 150 °C. |
Maximum evaporation of water |
200-10L/h. |
Centrifugal spray head transmission form |
Electric. |
Speed |
40,000 rpm |
Spray disc diameter |
80mm |
Heat source |
Electricity |
Electric heating maximum power |
18kw |
Total power |
22kw |
Dimensions L*W*H(mm) |
2500*1600*2800 |
Dry powder recovery |
≥98% |
