OLT Reactor series micro reactor is suitable for petroleum, chemical, chemical, pharmaceutical, polymer synthesis, metallurgy and other fields. For example, catalytic reaction, polymerization, supercritical reaction, high temperature synthesis, hydrogenation reaction, etc..
Model
|
OLT-HP-10 |
OLT-HP-25 |
OLT-HP-50 |
OLT-HP-100 |
OLT-HP-250 |
OLT-HP-500 |
volume(ml) |
10 |
25 |
50 |
100 |
250 |
500 |
Service temperature(℃) |
RT-350℃,Higher temperatures can be customized according to customer requirements |
|||||
Use pressure(Mpa) |
-0.1-10 Standard 10Mpa, customized according to customer requirements |
|||||
heating power(w) |
600 |
600 |
1000 |
1000 |
1500 |
1500 |
control mode |
PID artificial intelligence adjustment, LCD digital display |
|||||
Mixing form |
Magnetic stirring |
|||||
Mixing power(w) |
80 |
|||||
Stirring speed(rpm) |
0-1500 |
|||||
Positive and reverse regulation |
Positive inversion |
|||||
Temperature setting |
Self setting function of temperature |
|||||
safety protection |
Set upper temperature limit, over temperature alarm, self power-off protection |
|||||
Timing function |
Working time and holding time can be set regularly |
|||||
Timing function supply voltage |
AC 108V-240V 50Hz |
